Description for hexagon head setscrews

Dimension “A” applies after mounting. Before mounting it can be up to 2 mm smaller due to the release of the bending stress. hexagon head setscrews

All sizes in mm unless otherwise specified:

120mm Hole Centres

  • A = 120
  • B = 8
  • D = 9
  • D1 = 15
  • E = 26
  • F = 4
  • G = 13
  • H = 42
  • L = 138
  • L1 = 96
  • Load = 100Kg



140mm Hole Centres

  • A = 140
  • B = 8
  • D = 9
  • D1 = 15
  • E = 26
  • F = 4
  • G = 13
  • H = 42
  • L = 158
  • L1 = 116
  • Load = 100Kg



160mm Hole Centres

  • A = 160
  • B = 9
  • D = 9
  • D1 = 15
  • E = 28
  • F = 4
  • G = 13
  • H = 45
  • L = 178
  • L1 = 36
  • Load = 100Kg
